CMT Circular Saw Blade Wood Fine Cut, Ø160 x 20mm, Z=40
Available from 02.09.2026
€22.71
- 1x CMT fine-cut circular saw blade for wood, Ø160 x 20 mm, Z=40
IGM nástroje a stroje s.r.o.
Ke Kopanině 560 25267 Tuchoměřice Czech Republic
[email protected]
https://igmtools.de/
CMT Circular Saw Blade Wood Fine Cut, Ø160mm
CMT fine-cut circular saw blade for wood, Ø160 x 20 mm, Z=40 is a branded product from CMT Orange Tools (Italy). With a diameter of 160 mm, a bore of 20 (+16) mm, and Z=40 teeth, this circular saw blade is designed for versatile use in wood and wood-based materials.
The laser-cut steel body, combined with the tensioning ring, ensures precise concentricity and smooth operation. The teeth are tipped with industrial chrome carbide, maintaining sharpness for extended periods and reducing wear. Additionally, a hard-coated surface protects against corrosion and resin build-up.
Technical data
-
Diameter
Ø160 mm
-
Bore
Ø20 (+16) mm
-
Number of teeth
Z=40
-
Tooth geometry
ATB (Alternate Top Bevel)
-
Hook angle
16°
-
Cutting material
Carbide (HW), tungsten carbide-tipped
Features & benefits
- Industrial chrome carbide-tipped teeth for long service life and reduced wear
- Tri-metal brazing (silver-copper-silver) ensures high durability of the teeth
- Hard-coated surface protects against corrosion and resin build-up
- Laser-cut steel body with expansion ring for precise concentricity
- Damping slots reduce vibration and noise
- ATB (Alternate Top Bevel) for clean, splinter-free cutting edges
