Router Bits
Router bits also known as end mills or wood mills, are high speed routing tools for routers. There are hundreds of different shapes, sizes and lengths for many applications with the hand router or CNC router.
Today the most common routing bits are a combination of two materials. High speed steel (HSS or HW) for the shaft and body, and tungsten-carbide (TCT or HM) for the blades and tips. Routing bits may have one blade or several, the more blades a bit has the smoother and cleaner the cutting.
Read more
CMT Adjustable torque screwdriver set 1-6 Nm
Easy tightning | precise torque | for TC knives and reversible blades in router bits and planer heads
Item no.: I-CTW-006Delivery in 1-2 business days
Straight Cutter D 14 mm
D 14 mm | NL 50 mm | S 12 mm | GL 94 mm
Item no.: E-20084Delivery in 1-2 business days
Festool Plasterboard V-groove cutter HW S8 D32/90°
Shank 8 mm | D: 32 mm | NL: 16 mm | GL: 49 mm | alpha: 90°
Item no.: F-491001Delivery in 1-2 business days
Rounding Over Cutter D 34,9 mm
D 34,9 mm | S 12 mm | R1 6.35 mm | R2 4.75 mm
Item no.: E-14840Delivery in 1-2 business days
Festool Groove cutter HW S12 D18/45
Shank 12 mm | D: 18 mm | NL: 45 mm | GL: 90 mm
Item no.: F-491092Delivery in 1-2 business days
Festool Groove cutter HW S12 D20/45
Shank 12 mm | D: 20 mm | NL: 45 mm | GL: 90 mm
Item no.: F-491093Delivery in 1-2 business days
Ball cutter D: 25,4 mm
D: 32 mm l GL: 75 mm l S: 12 mm
Item no.: TI-TSB254-12Delivery in 1-2 business days
Festool Groove cutter HS S8 D 5/12
Shank 8 mm | D: 5 mm | NL: 12 mm | GL: 50 mm
Item no.: F-490943Delivery in 1-2 business days
Roman Ogee Cutter R 8 mm
R 8 mm | D 43 mm | NL 25 mm | S 8 mm | SL 32 mm
Item no.: E-14964Replenishment is on the way
Pierce and Trim Cutter D: 12 mm
D 12 mm | NL 25,4 mm | GL 84 mm | S 12 mm | SL 40 mm
Item no.: E-11810Delivery in 1-2 business days
Bead Cutter - 3.18mm Concave Radius
R 3,18 mm | D 38,1 mm | NL 6,35 mm | S 8 mm | SL 32 mm
Item no.: E-16920Delivery in 1-2 business days
Festool Groove cutter HW S8 D11/20
Shank 8 mm | D: 11 mm | NL: 20 mm | GL: 60 mm
Item no.: F-490961Delivery in 1-2 business days
Edge gear milling cutter with drill-in cutting edge HW Z2
D: 16,3 mm | L1: 9,5 mm | L2: 18 mm | GL: 70 mm | d: 12,3 mm
Item no.: TI-SC16.3-70-8Delivery in 1-2 business days
Weather Seal Cutter D: 46 mm
D: 46 mm | d: 36 mm | L1: 3 mm | L2: 5 mm | S: 8 mm
Item no.: TI-USD46-8Delivery in 1-2 business days
Festool Spiral groove cutter HS Spi S8 D18/25
Shank 8 mm | D: 18 mm | NL: 25 mm | GL: 57 mm
Item no.: F-490950Delivery in 1-2 business days
Slot Routing Cutter 24mm female thread M12
D: 24 mm l NL: 45 mm l GL: 75 mm
Item no.: TI-TM2445-M12Delivery in 1-2 business days
Face Milling Cutter D: 30 mm
D 30 mm | NL 12 mm | GL 55 mm | S 12 mm | SL 40 mm
Item no.: E-13442Delivery in 1-2 business days
Straight Cutter D 16 mm
D 16 mm | NL 30 mm | S 12 mm | GL 82 mm
Item no.: E-20180Delivery in 1-2 business days
Festool Flute cutter HW S8 R8
Shank 8 mm | D: 16 mm | NL: 11 mm | GL: 41 mm | R: 8 mm
Item no.: F-490985Delivery in 1-2 business days
Festool Groove cutter HW S8 D14/20
Shank 8 mm | D: 14 mm | NL: 20 mm | GL: 60 mm
Item no.: F-490964Delivery in 1-2 business days
Straight Cutter D 8 mm
D 8 mm | NL 20 mm | S 12 mm | GL 63 mm
Item no.: E-20080Delivery in 1-2 business days
Clamping ring set
ID: 8 mm | AD (OD): 14 mm | Allen Key: 5/64"
Item no.: T-COLL-8Delivery in 1-2 business days
Quality from professional manufacturers
The sautershop router bit range come from some of the worlds leading manufactures, for example TREND, established in 1955 they are the number one supplier in the UK. Also ENT, a german manufacturer, from whom we offer their complete range.
We offer the highest quality routing cutters that are also suitable for use by professional users. The spectrum ranges from HSS routing cutters for plastic processing, over carbide router cutters, tipped for wood and plastics processing to insertion routing cutters.
In addition, we also offer ultra high-end bits made completly from tungsten-carbide for long life and precision.
Large range of shaft diameters
We offer router cutters in metric shaft diameters of 3 mm, 6 mm, 8 mm and 12 mm. For the respective shaft diameter, an appropriate tool holder is required, i.e. a collet chuck, to ensure a secure fit of the router bit in the router. If you do not if you have a corresponding collet chuck for the bit shaft you require, you will find a large selection of collets for routers from many brands here.
How to find the right router bit
To select the right router cutters for your router, we recommend first selecting the desired shaft size and then the desired shape. The available cutter sizes will then be displayed of the selected router cutters shape.
If you do not find the right router cutters in our program or are not sure exactly what you need, plaese give us a call and our professional team will advise you
Safety instructions & care tips
Tool holder / Router cutter clamping:
Make sure that the collet used matches the shaft diameter of the cutter. Clamp the routing cutter up to the mark or at least 3/4 of the shaft length.
Reducing sleeves/ Collets:
We recommend using high-quality, multi-slotted collets to ensure that the routing cutter runs without vibration during continuous work. We only recommend using reducing sleeves when absolutly necessary. Before inserting the collet into the motor spindle, the collet must snap into the union nut to prevent jamming and wedging.
Router cutter extensions:
Used for extending the routing height, but only to be used in combination with a routing table. They are available with different shank sizes and with different sized collets.
Counter-directiona l/ synchronized operation:
The material feed must always be in the opposite direction to the rotation of the routing cutter. Never feed from the other side, except for special applications, a sutible kickback stop must be used,
Routing depths:
Rout greater depths in several steps. This extends the service life of the tools, ensures a better routing result and minimises risk.
Speed/Rotation:
Never exceed recommended maximum rotation speeds as indicated on the cutter shank, packaging or instructions.
Resharpening:
Use only sharp, intact and high quality routing cutters. If necessary, contact an appropriate sharpening service to have sharpening done. Dull and defective routing cutters pose an increased safety risk and create poor work.
FAQ - frequently asked questions about Router Bits
When choosing a router bit you should pay attention to the correct shaft diameter. In Europe 8 mm and 12 mm (metric shafts) are normal. In the USA or in the UK imperialsizes are more common, such as 1/4", 3/8" and 1/2". At sautershop you will find the shaft diameters 12 mm, 8 mm, 6 mm and 3 mm. Our largest selection is for router bits with 8 mm shaft. For bigger jobs, 12 mm shaft router bits normally have a large cutting edge diameter (greater than 35 mm).
With the classic Tungsten-Carbide Tipped bits (TCT), solid and natural woods, wood materials such as plywood, chipboard and MDF, plastics and acrylic can be processed.
For abrasive materials, such as Corian®, Hi-Macs® or Staron®, there are special router bits that have a more resistant carbide on the cutting edges.
Hardly any other machine is as versatile as a router. For this reason, there is an innumerable selection of wood router bits - regardless of whether you want to mill a chamfer, a groove, a rounding, a tine joint or the most diverse contours. Below you will find a selection of different types of routers:
- Slotter Bits: Most common router bit shape with straight cutting edges
- Spiral Flute Router Bits): Flute milling cutter, manufactured from solid tungsten-carbide
- Edge Processing Bits: rounding bits, chamfer bits, profile bits, edge moulding bits
- Template Routing: Flush routing bits with ball bearing on the cutting edge or on the shaft.
- Surface machining: Face milling cutter
- Rebate Routing: Rebater router bits
- Jointing: For milling tongue and groove joints, flat dowel joints
- Other Router Bits: T-slot routing cutters, prong bits / burr cutters, chamfer cutters, V-slot router bit.
The initial purchase cost of a router bit with replaceable blades (also known as an rota-tip bit) is more expensive than a standard tungsten-carbide tipped. In the long term if a bit is used regularly and intensively, it will prove more economical, the blades can often be rotated 180° to give double the cutting life . replacement blades are relatively inexpensive.
HW (TCT) stands for tungsten-carbide tipped), the cutting edges are a mixture of tungsten-carbide and cobalt.
Application: For all areas of wood processing, including plate materials and plastics.
Advantage: Clean resulst, long service life
VHW (solid Tungsten-carbide): Are normally a spiral router bits. Here the entire bit is made of solid tungsten-carbide.
Application: For work where extremely fine cutting edges are required, otherwise the application is the same as for TCT router bits.
HSS: High speed steel
Application: For work where extremely fine cutting edges are required: Ideal for soft wood, plastic and aluminium
Advantage: Extremely clean edges in softer materials but, has a short service life
DIA refers to router bits with daimond coated edges
Application: Generally for harder materials: chipboard, MDF, hardboard, laminates, veneers and mineral materials
Advantage: Very long service life.
A TCT router bit has a steel body with Tungsten-carbide cutting tips welded on. A solid tungsten-carbide bit has the blades milled into it, they are normally in a spiral form. They are often used with CNC routing machines, especially when large amounts of material needs to be removed.
In principle and groove cutting router bit can be used to drill a hole. They have downward facing blades allowing a drilling action. If you are intending to make several holes a 2 bladed bit is recommended
The correct speed to use is determined by the size of the router bit head
