Mekanika accessories
Modular accessories for every configuration
You can retrofit or upgrade any machine with accessories from Mekanika. From the 1,050 watt AMB high-performance spindle to the 2.2 kW VFD spindle, you can customise your machine to suit your applications. You have the option of enclosing the machines and much more.
Read more
safety first | spindle stop | accessible EMERGENCY STOP
Item no.: MEK-M00135Delivery in 1-2 business days
CAD & CAM from a single source | Supports DXF, DWG, SVG,...
Item no.: VE-VCARVE-PRODelivery in 1-2 business days
for all AMB motors (1 pair) | Quality carbon made in Germany
Item no.: SET-AMB-35635Delivery in 1-2 business days
Transparent dust protection shoe | magnetic brushes | for 43 mm clamping neck
Item no.: MEK-M01425Delivery in 1-2 business days
Suitable for: FAB | sacrificial plate with a grid of threaded inserts
Item no.: MEK-M01494Delivery in 4-5 business days
Accessories for vacuum tables
Item no.: MEK-M01332Delivery in 1-2 business days
Suitable for: EVO (S); PRO (S) | sacrificial plate with a grid of threaded inserts
Item no.: MEK-M01491Delivery in 1-2 business days
Adapted for FAB-CNC | Utilise maximum size | No clamping devices required
Item no.: MEK-M01344Delivery in 1-2 business days
Boom for suction unit | Ø100mm | Suitable for Mekanika FAB
Item no.: MEK-M01414Delivery in 2-3 business days
Suitable for: EVO (M); PRO (M) | sacrificial plate with a grid of threaded inserts
Item no.: MEK-M01492Delivery in 1-2 business days
2200 Watt | 5000 - 25000 rpm | ER20
Item no.: MEK-M00988Delivery in 1-2 business days
suitable for Mekanika EVO/PRO S
Item no.: MEK-M01593Delivery in 4-5 business days
Improve the height of your Z-axis to mill larger objects
Item no.: MEK-M01411Delivery in 1-2 business days
Boom for suction unit | Ø100mm | Suitable for Mekanika EVO/PRO
Item no.: MEK-M01417Delivery in 2-3 business days
suitable for Mekanika EVO/PRO L
Item no.: MEK-M01595Delivery in 4-5 business days
Improve the height of your Z-axis to mill larger objects
Item no.: MEK-M01409Delivery in 1-2 business days
Selection of end mills ranging from entry-level to professional for all types of machining.
Item no.: MEK-M01450Delivery in 1-2 business days
2200 Watt | 5000 - 25000 rpm | ER20
Item no.: MEK-M01408Delivery in 1-2 business days
suitable for Mekanika EVO/PRO M
Item no.: MEK-M01594Delivery in 4-5 business days
Adapted for EVO/PRO | Utilise maximum size | No clamping devices required
Item no.: MEK-M01600Delivery in 4-5 business days
Suitable for Mekanika EVO | Ø 43mm mount
Item no.: MEK-M01233Delivery in 1-2 business days
Selection of end mills ranging from entry-level to professional for all types of machining.
Item no.: MEK-M01448Delivery in 1-2 business days
Compatible with Mekanika EVO S
Item no.: MEK-M01501Delivery in 4-5 business days
A standardised workflow | Plug-and-play installation | Optical output power: 6 W
Item no.: MEK-M01412Delivery in 1-2 business days
Mekanika in comparison EVO vs. PRO vs. FAB
| Name/ Model | EVO model | PRO model | FAB model |
| Picture |  |
 |
 |
| Up to 3 available sizes (S, M, L) | Yes | Yes | One size fits all |
| Work surface | From 630 x 630 mm up to 1030 x 1030 mm | From 630 x 630 mm up to 1030 x 1030 mm | 1300 x 2700 mm |
| Starting price (without VAT) | From €2,200 | From 4.700€ | From 11.000€ |
| 5 year guarantee | Yes | Yes | Yes |
| Materials that you can mill | Wood, cork, PMMA (Plexiglas), HPL (Trespa), foam, ATH (Corian), carbon fibre, aluminium and much more... | All materials milled with EVO + stone and hard metals (brass, steel, etc.) | All materials milled with EVO + stone and hard metals (brass, steel, etc.) |
| Typical cutting speeds (softwood) | 2500mm/min | 5000mm/min | 7000mm/min |
| Typical cutting depth (softwood) | 0.5 x tool diameter | 0.7 x tool diameter | 0.8 x tool diameter |
| Linear guide system | V-groove wheels | Double linear rail HGR20 | Double HGR20 prismatic rail |
| Drive system (X-axis & Y-axis) | Steel-reinforced PU GT2 belts and pulleys Nema23 motor 2.2Nm | Ball screw 16mm Nema23 motor 2.2Nm | Y-axis: gear rack Mod 2 ±26µm / 1000mm (DIN5) and Nema34 motor 4.5Nm X-axis: ball screw 16mm and Nema34 motor 4.5Nm |
| Drive system (Z-axis) | T8 trapezoidal threaded spindle Nema23 motor 2.2Nm | Ball screw 16mm Nema23 motor 2.2Nm | Ball screw 16mm Nema23 motor 2.2Nm |
| Control unit (Planet CNC) | Yes | Yes | yes |
| Built-in computer (Raspberry Pi 4 - 2 GB RAM) | yes | yes | yes |
| User interface | 7" TFT IPS capacitive touchscreen Customised Bluetooth keyboard | 7" TFT IPS capacitive touchscreen Customised Bluetooth keyboard | Attachment: 13" capacitive touch screen Customised Bluetooth keyboard |
| Available spindles | AMB 1050 FME-1 AMB 1400 FME-P DI | AMB 1400 FME-P DI Air-cooled 2.2kW VFD | Air-cooled 2.2kW VFD |
| Tool length sensor | Yes | Yes | yes |
| Bundles available | EVO bundle / EVO education bundle | PRO bundle / PRO education bundle | FAB bundle |
| Complete technical data | EVO model | PRO model | FAB model |
Computer-aided woodworking with Mekanika CNC
Thanks to the large processing areas of up to 2,700 mm x 1,300 mm, Mekanika CNCs can process panel materials directly without pre-formatting. And with a precision that is in no way inferior to large machining centres.
The intuitive control via the 7-inch touchscreen enables you to produce your first professional results within a short time, even without prior CNC knowledge. And without several days of training!
The uncomplicated data transfer and connection to the CNC portal and the milling unit is important for the CNC control. Once the workpiece has been designed in the CAD/CAM software, the G-code can be easily transferred to the CNC machine via USB with the Mekanika. The rest is done by the driven milling motor and the milling tool used.
Modular accessories for every configuration
You can retrofit or upgrade any machine with the accessories from Mekanika. From the 1,050 watt AMB high-performance spindle to the 2.2 kW VFD spindle, you can customise your machine to suit your applications. You have the option of enclosing the machines and much more.
